Covestro FR3010 PC+ABS Plastic with Chemical Resistance

PC+ABS FR3010 is a halogen-free flame retardant PC ABS plastic with excellent chemical resistance, stress crack resistance, and good processability. Suitable for automotive, electronics, and electrical structural parts with customizable modification options.

No dude en contactarnos

  • Estructura del producto

01 | New generation flame retardant materials: integration of safety, environmental protection and structural reliability



With the improvement of global product safety standards, traditional halogen-containing flame retardant solutions are gradually being eliminated, and companies face more stringent comprehensive requirements when selecting materials:

  ・Materials must meet halogen-free environmental standards to reduce potential impacts on the environment and human body

  ・At the same time, they must have excellent structural strength, durability and adaptability to complex processing

  ・Applicable to variable working conditions, especially to cope with chemical corrosion and mechanical stress challenges

Based on this background, PC+ABS FR3010 developed by Covestro combines halogen-free flame retardant technology, good processing performance, stress cracking resistance and chemical resistance, and has become a high-performance PC ABS plastic solution that the market is concerned about.

Covestro FR3010



02 | In-depth analysis of key material characteristics



Different from ordinary PC/ABS and traditional flame-retardant plastics, PC+ABS FR3010 has the following multi-dimensional advantages:

→ Halogen-free flame-retardant formula, easy to cope with global certification

  ・Under UL 94 standard, 1.2mm thickness can reach V-1, 1.5mm and above can reach V-0, 3.0mm thickness can achieve 5VB/5VA

  ・Completely halogen-free, in compliance with international environmental regulations such as RoHS and REACH, and convenient for global market circulation

→ Non-reinforced system, taking into account toughness and processing flexibility

  ・Using non-reinforced formula to avoid processing difficulties caused by high fiber filling

  ・Maintain good fluidity and molding stability, suitable for complex structures and thin-walled parts production

→ Excellent stress cracking and chemical corrosion resistance

  ・Effective protection against cracking risks caused by environmental stress and mechanical loads

  ・Resistant to corrosion by common industrial chemicals, improving the overall service life and reliability of the product

→ Comprehensive electrical insulation and structural strength guarantee

  ・Volume resistivity up to 1E16 Ω·cm, insulation strength 35 kV/mm, reducing electrical hazards

  ・Notch impact strength 35 kJ/m² (23°C), still maintains toughness at low temperatures (-30°C)

  ・Tensile strength up to 60 MPa, excellent dimensional stability

→ Additive optimization to help efficient production

  ・Flame retardants ensure reliable flame retardant performance at various thicknesses

  ・Mold release agents improve demolding efficiency, reduce surface defects, and help mass production stability

→ PC+ABS Data Sheet

ULCondiciónEstándarValorUnidad
CTIIEC 601120SOCIEDAD ANÓNIMA
GWIT3,0 mmIEC 60695-2-13850°C
HolaTodos los colores 1,0 mmUL 746A0SOCIEDAD ANÓNIMA
Alta VelocidadUL 746A3SOCIEDAD ANÓNIMA
HWITodos los colores 3,0 mmUL 746A3SOCIEDAD ANÓNIMA
RTIElec   All Color 1.0mmUL 746B95°C
RTICadena todo color 3,0 mmUL 746B90°C
Resistividad volumétricaNorma ASTM D2571E+16Ω.cm
Rigidez dieléctricaNorma ASTM D14929kilovoltios/mm
Resistencia al arcoASTM D4956SOCIEDAD ANÓNIMA
Clasificación de llamaAll Color 1.2mmUL94V-1
Comportamiento mecánicoCondiciónEstándarValorUnidad
AlargamientoRendimiento 50 mm/minISO 5274.0%
AlargamientoRotura 50 mm/minISO 52750%
Impacto sin muescas Izod23ºCISO 180NÓTESE BIENkJ/m²
Impacto de muesca Izod23ºCISO 18035kJ/m²
Impacto de muesca Izod-30°CISO 18010kJ/m²
Resistencia a la tracciónRotura 50 mm/minISO 52750MPa
Resistencia a la tracciónRendimiento 50 mm/minISO 52760MPa
Módulo de tracción1,0 mm/minISO 5272700MPa
TérmicoCondiciónEstándarValorUnidad
HDT0,45MPaISO 75100°C
HDT1,8MPaISO 7590°C
CLEFlujo 23~55°CISO 113597.6E-5cm/cm/°C
CLExFlujo 23~55 °CISO 113598E-5cm/cm/°C
Temperatura de ablandamiento Vicat50 °C/h 50 NISO 306108°C
Temperatura de ablandamiento Vicat120 °C/h 50 NISO 306110°C
Propiedad fisicaCondiciónEstándarValorUnidad
Absorción de agua23ºCISO 620.5%
Absorción de agua23°C 50RH balanceISO 620.2%
ContracciónFlow 150x105x3mm 240°C Mold temperature:80°CISO 25770.5~0.7%
ContracciónxFlow 150x105x3mm 240°C Mold temperature:80°CISO 25770.5~0.7%
DensidadISO 11831.18gramos/cm³
Viscosidad de fusión260°C 1000sˉ1ISO 11443245Pa·s
Índice de fusión240°C 5kgISO 113315cm³/10min
Propiedades electricasCondiciónEstándarValorUnidad
CTISolución AIEC 60112350V
Constante dieléctrica1 MHzIEC 602503.1
Constante dieléctrica100 HzIEC 602503.2
Resistividad volumétricaCEI 600931E+16Ω.cm
Rigidez dieléctrica1,0 mmCEI 6024335kilovoltios/mm
Factor de disipación1 MHzIEC 602500.007
Factor de disipación100 HzIEC 602500.005
Resistividad superficialCEI 600931E16Ω
InflamabilidadCondiciónEstándarValorUnidad
Índice limitante de oxígenoMethodAISO 458932%
Clasificación de llamaAll Color 1.2mmUL94V-1
Clasificación de llamaTodos los colores 1,5 mmUL94V-0
Clasificación de llamaAll Color 2.0mmUL94V-0 5VB
Clasificación de llamaTodos los colores 3,0 mmUL94V-0 5VA



03 | Typical application areas: ideal choice for high-standard working conditions



PC+ABS FR3010 is widely used in the following application scenarios with strict requirements on safety, durability, and processability due to its comprehensive performance:

✔ Automotive interior and structural parts-instrument panels, functional accessories, electronic component housings

✔ Smart terminals and consumer electronics-routers, household appliance housings, smart home devices

✔ Electrical and industrial equipment-distribution boxes, connectors, structural parts, ensuring flame retardancy and chemical resistance

✔ Complex structural parts and high-reliability products-thin-wall parts, impact-resistant housings, long-term outdoor applications



04 | Address industry pain points and help product innovation and upgrading



Traditional PC/ABS and some low-end flame retardant plastics face the following pain points:

❌ Halogen-containing materials are difficult to meet environmental regulations, limiting global market expansion

❌ Lack of chemical corrosion resistance and stress cracking resistance, short product life

❌ High reinforcement system leads to complex processing and unstable product yield

PC+ABS FR3010 comprehensively solves the above problems through halogen-free flame retardant, chemical corrosion resistance, stress cracking resistance and non-reinforced system, ensuring simultaneous improvement of product performance, compliance and manufacturing efficiency.



05 | Our advantages: not only supply, but also flexible customization and technical support



As a professional trading partner for plastic raw materials, we not only supply standard PC ABS FR3010 raw materials, but also help customers quickly match product needs through a strong supply chain and technical team:

✅ Provide customized modification services, and adjust performance parameters such as toughness, fluidity, and flame retardant grade in a personalized manner

✅ Multi-brand, multi-specification supply channels to meet different application and budget requirements

✅ The technical team provides full support to assist in material selection, formula optimization, and processing plan formulation

✅ Efficient and flexible trade services to reduce development costs and supply risks



06 | Conclusion: Choosing materials is also choosing flexible and reliable supply cooperation



In the face of increasingly stringent product safety standards and market competition, it is difficult to fully meet the needs of corporate innovation and market layout by relying solely on standard materials. We focus on the supply of PC+ABS plastics and a variety of high-performance engineering materials, combined with flexible modification solutions, technical services and global channel resources to help your products stand out in complex application environments.

Welcome to consult and obtain detailed technical information, sample solutions and customized modification support of PC+ABS FR3010, and work together to create safer, more reliable and more competitive product solutions.
