Covestro FR3000 PC ABS Plastic Material with Light Stability
Estructura del producto
01 | New generation PC+ABS FR3000, enabling high-standard product design
As the automotive, electrical and electronic, home appliance and other industries put forward more stringent requirements on material performance, PC ABS plastic material with excellent flame retardancy, processability and appearance performance has become the focus of the market. PC+ABS FR3000 launched by Covestro is a halogen-free flame retardant solution developed for high-performance fields, which combines high fluidity, light stability and good structural strength to meet the molding and durability requirements of complex products.
02 | PC ABS Plastic Material highlights: Performance balance beyond traditional PC ABS
PC+ABS FR3000 is based on polymer blending technology, combining the strength and heat resistance of polycarbonate (PC) with the toughness and processability of ABS resin. At the same time, by scientifically adding flame retardants and release agents, it brings the following core advantages:
✅ Halogen-free flame retardant, in line with V-0, 5VB, 5VA multi-level fire protection standards
✅ High fluidity, helping complex thin-walled structures to be efficiently injection molded
✅ Light-stable formula, improving the outdoor durability and appearance of products
✅ Excellent electrical performance, volume resistance 1E+16 Ω.cm, insulation strength up to 35 KV/mm
✅ Good impact resistance and dimensional stability, taking into account mechanical strength and reliability
Different from conventional plastics, FR3000 is positioned in high-end application fields that have synchronous requirements for flame retardancy, processing efficiency and product aesthetics, and is a typical technical pc abs plastic material representative.
03 | Application fields: Leading the material upgrade of the automotive and electronics industries
Facing the trend of intelligence and lightweight, PC+ABS FR3000 has been widely used in:
・Automotive interior and exterior trims, functional structural parts, meeting high standards of flame retardancy and strength requirements
・Electronic and electrical housings, switch panels, connectors, taking into account both safety and aesthetic design
・Smart device housings, home appliance parts, providing excellent appearance and processing efficiency
・Industrial equipment accessories, improving durability and stability
Especially in cutting-edge fields such as new energy vehicles, 5G terminals, and smart homes, PC abs plastic materials with flame retardancy, light stability, and high fluidity have become the preferred materials for design engineers.
04 | Technical Data That Reflects Real Performance
UL | Condición | Estándar | Valor | Unidad | |||
CTI | IEC 60112 | 2 | SOCIEDAD ANÓNIMA | ||||
GWFI | 0,75 mm | IEC 60695-2-12 | 900 | °C | |||
GWIT | 3,0 mm | IEC 60695-2-13 | 800 | °C | |||
Hola | Todos los colores 0,75 mm | UL 746A | 0 | SOCIEDAD ANÓNIMA | |||
Hola | Todos los colores 3,0 mm | UL 746A | 0 | SOCIEDAD ANÓNIMA | |||
Alta Velocidad | UL 746A | 1 | SOCIEDAD ANÓNIMA | ||||
HWI | Todos los colores 0,75 mm | UL 746A | 3 | SOCIEDAD ANÓNIMA | |||
HWI | Todos los colores 3,0 mm | UL 746A | 1 | SOCIEDAD ANÓNIMA | |||
RTI | Elec All Color 1.0mm | UL 746B | 90 | °C | |||
RTI | Str Todos los colores 1,5 mm | UL 746B | 85 | °C | |||
RTI | Str All Color 2.0mm | UL 746B | 85 | °C | |||
RTI | Cadena todo color 3,0 mm | UL 746B | 90 | °C | |||
Resistividad volumétrica | Norma ASTM D257 | 1E+16 | Ω.cm | ||||
Ball pressure | IEC 60695-10-2 | 88 | °C | ||||
Rigidez dieléctrica | Norma ASTM D149 | 33 | kilovoltios/mm | ||||
Resistencia al arco | ASTM D495 | 5 | SOCIEDAD ANÓNIMA | ||||
Clasificación de llama | All Color 2.0mm | UL94 | V-0 5VB | ||||
Clasificación de llama | Todos los colores 3,0 mm | UL94 | V-0 5VA | ||||
Comportamiento mecánico | Condición | Estándar | Valor | Unidad | |||
Alargamiento | Rendimiento 50 mm/min | ISO 527 | 3.5 | % | |||
Alargamiento | Rotura 50 mm/min | ISO 527 | 40 | % | |||
Impacto sin muescas Izod | 23ºC | ISO 180 | NÓTESE BIEN | kJ/m² | |||
Impacto de muesca Izod | 23ºC | ISO 180 | 35 | kJ/m² | |||
Impacto de muesca Izod | -30°C | ISO 180 | 10 | kJ/m² | |||
Resistencia a la tracción | Rotura 50 mm/min | ISO 527 | 45 | MPa | |||
Resistencia a la tracción | Rendimiento 50 mm/min | ISO 527 | 60 | MPa | |||
Módulo de tracción | 1,0 mm/min | ISO 527 | 2700 | MPa | |||
Térmico | Condición | Estándar | Valor | Unidad | |||
HDT | 0,45MPa | ISO 75 | 92 | °C | |||
HDT | 1,8MPa | ISO 75 | 82 | °C | |||
CLE | Flujo 23~55°C | ISO 11359 | 7.6E-5 | cm/cm/°C | |||
CLE | xFlujo 23~55 °C | ISO 11359 | 8E-5 | cm/cm/°C | |||
Temperatura de ablandamiento Vicat | 50 °C/h 50 N | ISO 306 | 95 | °C | |||
Temperatura de ablandamiento Vicat | 120 °C/h 50 N | ISO 306 | 97 | °C | |||
Propiedad fisica | Condición | Estándar | Valor | Unidad | |||
Absorción de agua | 23ºC | ISO 62 | 0.5 | % | |||
Absorción de agua | 23°C 50RH balance | ISO 62 | 0.2 | % | |||
Contracción | Flow 150x105x3mm 240°C Mold temperature:80°C | ISO 2577 | 0.5~0.7 | % | |||
Contracción | xFlow 150x105x3mm 240°C Mold temperature:80°C | ISO 2577 | 0.5~0.7 | % | |||
Densidad | ISO 1183 | 1.18 | gramos/cm³ | ||||
Viscosidad de fusión | 260°C 1000sˉ1 | ISO 11443 | 160 | Pa·s | |||
Índice de fusión | 240°C 5kg | ISO 1133 | 24 | cm³/10min | |||
Propiedades electricas | Condición | Estándar | Valor | Unidad | |||
CTI | Solución A | IEC 60112 | 350 | V | |||
Constante dieléctrica | 1 MHz | IEC 60250 | 3.1 | ||||
Constante dieléctrica | 100 Hz | IEC 60250 | 3.2 | ||||
Resistividad volumétrica | CEI 60093 | 1E+16 | Ω.cm | ||||
Rigidez dieléctrica | 1,0 mm | CEI 60243 | 35 | kilovoltios/mm | |||
Factor de disipación | 1 MHz | IEC 60250 | 0.006 | ||||
Factor de disipación | 100 Hz | IEC 60250 | 0.005 | ||||
Resistividad superficial | CEI 60093 | 1E16 | Ω | ||||
Inflamabilidad | Condición | Estándar | Valor | Unidad | |||
Clasificación de llama | Todos los colores 1,5 mm | UL94 | V-0 | ||||
Clasificación de llama | All Color 2.0mm | UL94 | V-0 5VB | ||||
Clasificación de llama | Todos los colores 3,0 mm | UL94 | V-0 5VA |
05 | Analysis of technical advantages: How does FR3000 meet stringent standards?
PC+ABS FR3000 has passed a number of international standard tests to fully verify its comprehensive performance:
✔ UL94 fire rating up to 5VA, ensuring flame retardant performance in extreme environments
✔ GWIT up to 800°C, GWFI up to 960°C, improving heat resistance and safety factor
✔ Excellent electrical resistance and dimensional stability, suitable for high-precision structural parts
✔ High-flow formula (melt index 24 cm³/10min), optimizes the injection molding process of complex products
✔ Vicat softening temperature up to 97°C, ensuring the heat resistance and stability of products
These characteristics enable FR3000 to achieve a balance between electrical safety, mechanical properties and processing efficiency, making it an ideal material choice for high-demand products.
06 | Trader Advantages: Providing Standard and Customized PC ABS Solutions
As a professional plastic raw material supplier, we not only provide Covestro PC+ABS FR3000 standard specifications, but also provide personalized modification and supporting services according to different customer needs:
🔧 Customizable high impact resistance, chemical resistance, reinforcement, UV resistance and other multifunctional solutions
📊 Support flexible combinations of different colors, fluidity, and environmental protection levels
⏩ Quick response, technical support and sample development are carried out simultaneously to reduce trial and error costs
🌍 Global supply chain network to ensure stable delivery and product compliance
Compared with single brand channels, we focus on flexible, efficient and practical pc abs plastic material overall solutions to help companies speed up product development, upgrade performance and enhance market competitiveness.
07 | Conclusion: Choose FR3000 to create safer and more efficient innovative products
PC+ABS FR3000 is not only a single plastic particle, but also a comprehensive material platform that integrates flame retardancy, safety, appearance and processing advantages. Whether it is new energy vehicles, smart electronics, industrial equipment, or home appliances, Covestro FR3000 helps engineering design break through traditional limitations with its high fluidity and light stability.
If you need reliable performance, stable supply, and customizable pc abs plastic material, please contact us to obtain professional technical information and personalized modification solutions to jointly create high-performance products that meet future trends.
08 | Related Products: Explore More High-Performance PC+ABS Plastic Material Options
In addition to FR3000, we offer a full range of pc abs plastic material solutions to meet diverse performance and processing needs:
Brand | Material Name | Modelo de producto | Densidad | Melt Flow Index | Key Data Summary | Descripción |
Covestro | PC+ABS | T85 XF | 1.14 g/cm³ | 19 cm³/10min | Flame Rating: HB Melt Flow Index: 19 cm³/10min Notched Impact: 48 kJ/m² Heat Deflection Temp: 126°C | Compliance: UL Material Features: High Flow • Non-reinforced |
Covestro | PC+ABS | T65 XF | 1.13 g/cm³ | 18 cm³/10min | Flame Rating: HB Melt Flow Index: 18 cm³/10min Notched Impact: 48 kJ/m² Heat Deflection Temp: 122°C | Compliance: UL Material Features: High Flow • Non-reinforced |
Beyond standard grades, we also provide customized modification services, including enhanced weatherability, chemical resistance, reinforcement, or UV stability, helping you optimize product performance while reducing development risks.
