Techmer PPSU GF25 LE Polyphenylsulfone with Low Extractables Material

Techmer PPSU GF25 LE is a 25% glass fiber reinforced, V-0 flame-rated Polyphenylsulfone with low extractables, high heat resistance, and stable mechanical performance. Ideal for medical devices, electrical components, and high-temperature industrial parts, supporting complex injection-molded designs and long-term reliability.

liên hệ với chúng tôi

  • Cấu trúc sản phẩm

What is PPSU Polymer



Tycoma PPSU GF25 LE (Polyphenylsulfone) is a 25% glass fiber-reinforced, V-0 flame-retardant thermoplastic. Its low extractables, high heat resistance, and mechanical stability make it a preferred material for medical devices, electrical and electronic equipment, and high-temperature industrial parts. When selecting a material, buyers must consider not only basic performance but also long-term reliability, processability, and supply chain stability. PPSU GF25 LE excels in these areas.

Tycoma PPSU GF25 LE



01 | Material Core Properties



It takes into account both mechanical properties and toughness

Polyphenylsulfone itself has good toughness, while glass fiber reinforcement provides high rigidity, ensuring that the parts will not crack when subjected to stress and impact. It is particularly suitable for parts with complex structures and thin walls.

Thermal performance and dimensional stability

The high heat distortion temperature and low coefficient of linear expansion enable PPSU GF25 LE to be used for a long time in high-temperature environments, maintain shape stability, and reduce the risk of failure caused by thermal cycling.

Low extract and safety

The low extract characteristics meet the strict hygiene requirements of medical devices, food contact parts, etc., while the flame retardant grade V-0 ensures the safety of electrical and high-temperature applications.

Chemical tolerance and environmental adaptability

It has a good tolerance to a variety of chemicals and disinfectants, is suitable for medical, chemical and high-temperature industrial environments, and can extend the service life of parts.



02 | Process Adaptation and Processing Guide



Processing Method: Ép phun

Processing Advantages: Excellent flowability, adaptable to complex geometries and thin-walled part designs.

Ghi chú: At high fill rates, mold temperature and injection speed must be optimized to balance molding accuracy and mechanical properties.



03 | Industry Application Analysis



Medical Devices

Low extractables and high heat resistance are suitable for syringes, surgical instrument handles, and sterilized reusable parts. V-0 flame retardancy ensures safe operation and meets FDA and ISO medical standards.

Electronic and Electronic Applications

High-temperature connectors, switch housings, and motor components require high insulation strength and heat resistance.PPSU GF25 LE's stable electrical properties and heat deflection temperature ensure increased reliability over long-term operation.

High-temperature industrial parts

For applications such as chemical equipment and corrosion-resistant structural components, PPSU GF25 LE offers high mechanical strength and dimensional stability, enabling it to withstand complex working conditions.



04 | Polyphenylsulfone PPSU GF25 LE Data Sheet



Hành vi cơ họcTình trạngTiêu chuẩnGiá trịĐơn vị
Độ giãn dàiNăng suấtASTM D6383.0%
Độ bền uốnASTM D790172MPa
Mô đun uốnASTM D7906890MPa
Tác động của Izod Notch23℃ 3.20mmASTM D256110J/m
Độ bền kéoNăng suấtASTM D638118MPa
nhiệtTình trạngTiêu chuẩnGiá trịĐơn vị
HDTKhông ủ 0,45MPaASTM D648216
HDTChưa ủ 1,80MPaASTM D648216
SẠCHChảyASTM D6963.6E-5cm/cm/℃
Tài sản vật chấtTình trạngTiêu chuẩnGiá trịĐơn vị
Sự hấp thụ nước24 giờASTM D5700.70%
co ngótFlow 3.20mmASTM D9550.50%
Tỉ trọngASTM D7921.43g/cm³
Tính chất điệnTình trạngTiêu chuẩnGiá trịĐơn vị
Điện trở suất thể tíchASTM D2571E16Ω.cm
Độ bền điện môiShort TimeASTM D14919KV/mm
độ cứngTình trạngTiêu chuẩnGiá trịĐơn vị
Độ cứng RockwellR(Tỷ lệ)ASTM D785120
Tính dễ cháyTình trạngTiêu chuẩnGiá trịĐơn vị
Xếp hạng ngọn lửa1,6mmUL94V-0



05 | Selection and purchasing suggestions



Performance-first application: When mechanical strength, heat resistance and flame retardancy are the core requirements, PPSU GF25 LE is the preferred choice.

Resilient priority applications: For medical or precision electronic components that require higher impact toughness, low glass fiber or fiber-free grade Polyphenylsulfone can be considered.

Supply chain stability: It is recommended to choose suppliers with multi-source procurement capabilities and technical support to ensure continuous supply of materials and technical services.

Tycoma PPSU GF25 LE



06 | Reference for comparison of similar materials



Material ModelReinforcement TypeTỉ trọngKey Properties & Application Scenarios
PPSU GF25 LE25% Glass Fiber1.43 g/cm³Balanced rigidity and toughness, low extractables. Suitable for medical devices, electrical parts, and high-temperature industrial components.
PPSU GF30 LE30% Glass Fiber1.47 g/cm³Higher stiffness, ideal for load-bearing structural parts such as high-performance electrical connectors.
PPSU GF30 TL10 LE30% Glass Fiber + 10% PTFE1.50 g/cm³Enhanced with PTFE for better lubricity and flowability. Recommended for high-temperature electronic and industrial components with wear resistance needs.
PPSU GF1010% Glass Fiber1.36 g/cm³Higher impact toughness, easy to process. Suitable for thin-wall medical parts and precision small components.
PPSU GF2020% Glass Fiber1.43 g/cm³Balanced stiffness and toughness, suitable for medium-load parts such as medical instruments and electronic housings.
PPSU GF4040% Glass Fiber1.63 g/cm³Very high stiffness and dimensional stability. Ideal for heavy-duty, high-temperature environments such as industrial structural components.



07 | Juyuan supply advantage



Global multi-source procurement: Ensuring a continuous supply of Polyphenylsulfone materials

Technical support: Assist customers in model selection, process optimization and application implementation

Flexible delivery: Supports small-batch sample production to large-scale mass production

Customized service: Color, batch and special requirements can be adjusted according to customer needs
