4TECH® 9W22110 PSU: Medium Flow & Fiber Reinforced
Cấu trúc sản phẩm
What is PSU
4TECH® 9W22110 is a 10% glass fibre reinforced flame-retardant PSU (polysulfone) material with excellent thermal stability, flame retardancy and electrical insulation properties. Its UL94 V-0 flame retardancy rating, combined with excellent mechanical strength and electrical properties, makes it widely used in electrical appliances, automobiles and medical equipment.
01 | Product Highlights
Reinforced Structure: 10% glass fibre reinforcement enhances strength and rigidity, making it suitable for long-term use in engineering components.
Flame Retardant Performance: UL94 V-0 rating meets electrical and safety requirements.
Mechanical Properties: Tensile strength of 80 MPa and tensile modulus of 4000 MPa balance rigidity and durability.
Electrical Insulation: Volume resistivity and surface resistivity both reach the 1E15 Ω level, ensuring electrical safety.
Moderate Flowability: Moderate flowability, suitable for injection moulding of complex structures.
02 | Ứng dụng tiêu biểu
Electrical components: insulating elements, switch housings, relay seats.
Ngành công nghiệp ô tô: Flame-retardant structural components, heat-resistant electrical modules.
Medical equipment: steam-resistant and flame-retardant enclosures and accessories.
Linh kiện công nghiệp: Engineering components that can withstand long-term temperatures and stress cracking.
03 | Process adaptation
Phương pháp chế biến: Injection molding.
Recommended wall thickness: ≥1.6mm to fully leverage the flame retardant grade.
Suitable for modification: It can further increase the glass fiber content or be customized in color.
04 | 4TECH® 9W22110 Data Sheet
Hành vi cơ học | Tình trạng | Tiêu chuẩn | Giá trị | Đơn vị | |||
Độ giãn dài | Break 23℃ 5mm/min | ISO 527 | 4 | % | |||
Tác động của Izod Notch | 23℃ | ISO 180 | 5.5 | kJ/m2 | |||
Độ bền kéo | Break 23℃ 5mm/min | ISO 527 | 80 | MPa | |||
Mô đun kéo | 23℃ 5mm/min | ISO 527 | 4000 | MPa | |||
Tài sản vật chất | Tình trạng | Tiêu chuẩn | Giá trị | Đơn vị | |||
Tỉ trọng | ISO 1183 | 1.32 | g/cm³ | ||||
Tính chất điện | Tình trạng | Tiêu chuẩn | Giá trị | Đơn vị | |||
Điện trở suất thể tích | IEC 60093 | 1E15 | Ω.cm | ||||
Điện trở bề mặt | IEC 60093 | 1E15 | Ω | ||||
Tính dễ cháy | Tình trạng | Tiêu chuẩn | Giá trị | Đơn vị | |||
Xếp hạng ngọn lửa | 1,6mm | UL94 | V-0 |
05 | Industry value and trends
With the development of the electrification and new energy vehicle industry, the demand for high-temperature resistant, flame-retardant and electrically insulating plastics continues to grow. PSU, as a transparent to semi-transparent engineering plastic, is becoming a popular alternative to metals and other engineering plastics due to its dimensional stability, flame retardancy and hydrolysis resistance.
06 | Similar recommendations
If you are examining PSU system materials, in addition to 4TECH® 9W22110, you may also pay attention to:
nhà chế tạo | Mô hình sản phẩm | Value Summary | Sự miêu tả | Tỉ trọng |
4Plas | 9W20001 | Flammability Rating: HB | Material Properties: Medium Flow • Non-reinforced | 1.24 g/cm³ |
07 | FAQ
Q1: What are the differences between 4TECH® 9W22110 and a regular PSU?
A1: Compared with unreinforced PSU, 9W22110 is added with 10% glass fiber and features V-0 flame retardancy, offering higher mechanical strength and safety. It is suitable for the electrical and automotive industries.
Q2: Is this PSU suitable for medical devices?
A2: Yes, this material features high-temperature resistance, steam sterilization resistance and flame retardancy, making it suitable for medical equipment casings and long-term use components.
Q3: Can 4TECH® 9W22110 replace metal parts?
A3: In lightweight components with high requirements for electrical insulation and temperature resistance, this material can replace some metal parts, reducing weight and enhancing design flexibility.
Q5: How does Juyuan ensure the supply of materials?
A5: Juyuan ensures stable supply for bulk and long-term projects through multi-channel procurement and a stable international trade network, and can provide support for the selection of various engineering plastics such as PSU.
08 | Juyuan supply advantage
As a supplier specializing in international trade of plastic raw materials, Juyuan can provide customers with:
・Stable supply through multiple channels to ensure the demands of both bulk and long-term projects.
・Professional material selection support helps customers quickly match the most suitable PSU grade.
・Flexible logistics and export solutions enhance the cross-border purchasing experience.
