Lupoy HR5007AC Heat Resistant Polcarbonate ABS Plastic & TDS
Product Struction
What is Polcarbonate ABS Plastic - LG Lupoy HR5007AC
Against the backdrop of the rapid development of automotive lightweighting and electronic product integration, engineering plastics that combine structural strength, flame retardant safety and processing flexibility have become the focus of attention for manufacturing enterprises. Lupoy HR5007AC, as a high-end Polcarbonate ABS Plastic compound under LG Chem, is a representative material launched in response to the demands of this industry.
01 | Material highlights: It features high fluidity, flame retardancy, heat resistance, and low-temperature impact resistance
Lupoy HR5007AC is an injection-grade polcarbonate ABS plastic material, which combines the heat resistance and impact resistance of polycarbonate (PC) with the good processing fluidity of ABS, making the overall performance more balanced. Typical advantages include:
✔ Excellent flame retardant performance: Passed UL94 HB~5VA multiple flame retardant grades, adapted to different thicknesses and high safety standards.
✔ Heat resistance and durability: Vicat softening temperature is as high as 131°C, which meets the long-term use environment of electronic appliances and automotive interiors.
✔ High fluidity helps complex mold design: The melt index of 18 g/10min reduces the processing threshold and improves the appearance accuracy of the finished product.
✔ Excellent low-temperature impact toughness: Even in cold environments, the material still maintains good structural strength and is suitable for winter use in automobiles.
02 | Typical application scenarios
Automotive interiors and functional components: Lupoy HR5007AC is widely used in instrument panel structures, interior panels, and bracket systems, meeting the comprehensive requirements of lightness, safety, and aesthetics.
In the field of electronics and electrical appliances: Its excellent flame retardancy and electrical performance make it particularly suitable for household appliance casings and electronic component protective covers, enhancing the safety factor of products.
Structural components with strict requirements for heat resistance and flame retardancy: including industrial equipment casings, power tool accessories, etc.
03 | Polcarbonate abs material data sheet
UL | Condition | Standard | Value | Unit | |||
CTI | IEC 60112 | 0 | PLC | ||||
HAI | All Color 1.6mm | UL 746A | 1 | PLC | |||
HAI | All Color 3.0mm | UL 746A | 1 | PLC | |||
HVTR | UL 746A | 4 | PLC | ||||
HWI | All Color 1.6mm | UL 746A | 3 | PLC | |||
HWI | All Color 3.0mm | UL 746A | 3 | PLC | |||
RTI | Elec All Color 1.6mm | UL 746B | 60 | °C | |||
RTI | Elec All Color 3.0mm | UL 746B | 60 | °C | |||
RTI | Imp All Color 1.6mm | UL 746B | 60 | °C | |||
RTI | Imp All Color 3.0mm | UL 746B | 60 | °C | |||
RTI | Str All Color 1.6mm | UL 746B | 60 | °C | |||
RTI | Str All Color 3.0mm | UL 746B | 60 | °C | |||
Arc Resistance | ASTM D495 | 6 | PLC | ||||
Flame Rating | All Color 1.6mm | UL94 | HB | ||||
Flame Rating | All Color 3.0mm | UL94 | HB | ||||
Mechanical behavior | Condition | Standard | Value | Unit | |||
Elongation | Break 50mm/min | ISO 527 | 100 | % | |||
Flexural Strength | 2.0mm/min | ISO 178 | 80 | MPa | |||
Flexural Modulus | 2.0mm/min | ISO 178 | 2200 | MPa | |||
Izod Notch Impact | 23°C 4.0mm | ISO 180 | 46 | kJ/m² | |||
Tensile Strength | Yield 50mm/min | ISO 527 | 50 | MPa | |||
Thermal | Condition | Standard | Value | Unit | |||
Vicat Softening Temperature | 50°C/hr 50N | ISO 306 | 131 | °C | |||
Physical property | Condition | Standard | Value | Unit | |||
Shrinkage | Flow 3.2mm | INTERNAL METHOD | 0.5~0.8 | % | |||
Density | ISO 1183 | 1.14 | g/cm³ | ||||
Melt Index | 250°C 2.16kg | ISO 1133 | 4 | g/10min | |||
Melt Index | 260°C 5kg | ISO 1133 | 18 | g/10min | |||
Flammability | Condition | Standard | Value | Unit | |||
Flame Rating | All Color 1.6mm | UL94 | HB | ||||
Flame Rating | All Color 3.0mm | UL94 | HB |
04 | Why choose Lupoy HR5007AC?
Facing the urgent market demand for materials with high safety and reliability, the comprehensive performance of Lupoy HR5007AC is particularly outstanding and is especially suitable for:
・Manufacturing enterprises that pursue high-efficiency injection molding
・Application fields with strict requirements for heat resistance and flame retardancy
・Scenarios where materials need to maintain their toughness under low-temperature impact
In addition, as an important model of LG Chem's Lupoy series, the HR5007AC has a stable supply chain and global certification resources, which helps customers achieve rapid product launch.
05 | Series recommendation: More PC+ABS material options
If you are concerned about different performance combinations, the following Lupoy series PC+ABS materials can be flexibly combined:
Manufacturer | Material Name | Product Model | Density | Melt Flow Index | Key Data Summary |
LG Chem | PC+ABS | HR5007A | 1.14 g/cm³ | 5.3 g/10min | Flame Rating: HB Melt Flow Index: 5.3 g/10min Notched Impact: 65 kJ/m² |
LG Chem | PC+ABS | HR-5006A | 1.13 g/cm³ | 4 g/10min | Melt Flow Index: 4 g/10min Notched Impact: 60 kJ/m² Heat Deflection Temperature: 123 °C |
We can offer a variety of formula suggestions based on specific projects to help you reduce development risks and enhance production efficiency.
06 | One-stop supply service for plastic raw materials
As a professional supplier of Polcarbonate ABS Plastic, we not only offer original factory stock of Lupoy HR5007AC, but also support flexible selection of multiple brands and models. We cooperate with the technical team to provide material application consultation and help customers optimize the product structure and performance.
Need to know more technical information about Lupoy HR5007AC or get samples? Welcome to contact us at any time to get customized solutions.
