LyondellBasell LDPE 2420D Plastics Properties Uses and TDS
Productconstructie
What is LDPE 2420D Plastics
LUPOLEN LDPE 2420D is a general-purpose low-density polyethylene ldpe plastic material launched by LyondellBasell. It has excellent mechanical properties and bubble stability and is widely used in blow molding extrusion applications such as flexible packaging, agricultural film, and stretch hood packaging. Its high melt strength and additive-free characteristics provide users with pure and high-performance ldpe plastics solutions.
01 | Three core features: stable foam, high strength, and universal adaptability
High melt strength and good bubble stability
LDPE 2420D plastic has a melt index of 0.25 g/10min, high melt strength, is not easy to collapse bubbles in film blowing, and has uniform film formation. It is particularly suitable for high barrel-diameter ratio, wide-width agricultural film or multi-layer co-extrusion middle layer.
Excellent mechanical strength and ductility
With a longitudinal tensile strength of 27 MPa, a vertical elongation at break of 500%, and a tensile modulus of 260 MPa, it has good support and tear resistance after film formation, making it very suitable for heavy packaging bags and stretch cover films.
Additive-free pure formula
This grade does not contain anti-blocking agents, lubricants or antistatic additives, and is suitable for customers with high purity requirements, such as food-grade packaging or companies that need to customize modified masterbatch ratios.
02 | In-depth exploration of application areas: multiple values from packaging bags to agricultural films
▶ Flexible packaging and heavy packaging bags
High toughness and good processability make it outstanding in industrial packaging bags and building materials packaging films, able to withstand handling shocks and maintain a firm seal.
▶ Agricultural film application
LDPE 2420D's good transparency and puncture resistance (6.5 J/mm) make it suitable for use in fields such as agricultural land covering films and greenhouse films, maintaining mechanical integrity and service life under different climatic conditions.
▶ Stretch hood film and shrink film
On the automated shrink packaging line, LDPE 2420D exhibits good heat shrink consistency and uniform stretching performance, and can be used for assembly outsourcing protection in the beverage, home appliance and other industries.
▶ Blown film and liner film
Suitable for express bags, envelope films, shopping bags, industrial liner bags, etc., meeting the production requirements of high strength, no impurities, and uniform thickness.
03 | Processing suggestions and precautions
Film blowing temperature control: It is recommended that the barrel temperature be 170–200°C, and the die temperature be slightly higher to stabilize the inflation ratio;
Thickness recommendation: Suitable for various film products of 40–100μm;
Extrusion application: It can be used as a co-extrusion film substrate layer, and it is recommended to be matched with EVA or mPE to improve flexibility;
Processing equipment matching: It is suitable for all mainstream extrusion and film blowing equipment, with stable fluidity, easy thickness control and die uniformity.
04 | Data Overview: LDPE 2420D Technical Parameter Table
Extrusiegieten | Voorwaarde | Standaard | Waarde | Eenheid | |||
Smelten | Temperatuur | 170~220 | °C | ||||
Mechanisch gedrag | Voorwaarde | Standaard | Waarde | Eenheid | |||
Verlenging | Flow Break 50μm Blown Film | ISO527 | 200 | % | |||
Verlenging | xFlow Break 50μm Blown Film | ISO527 | 500 | % | |||
Vallen | Weight Impact Strength F50 50μm Blown Film | ASTM D1709 | 250 | G | |||
Wrijving | Coefficient 50μm Blown Film | ISO 8295 | 0.8 | ||||
Lek | Resistance Failure Energy 70μm Film | DIN 53373 | 6.5 | J/mm | |||
Treksterkte | Module | ISO527 | 260 | MPa | |||
Treksterkte | Sterkte opbrengst | ISO527 | 10 | MPa | |||
Treksterkte | Strength Flow 50μm Blown Film | ISO527 | 27 | MPa | |||
Treksterkte | Strength xFlow 50μm Blown Film | ISO527 | 25 | MPa | |||
Optische prestaties | Voorwaarde | Standaard | Waarde | Eenheid | |||
Glans | 20° | ASTM D2457 | 15 | ||||
Glans | 60° | ASTM D2457 | 50 | ||||
Nevel | 50μm | ASTM D1003 | 14 | % | |||
Fysieke eigendom | Voorwaarde | Standaard | Waarde | Eenheid | |||
Dikte | ISO1183 | 0.923 | g/cm³ | ||||
Smelten | Index 190°C 2,16 kg | ISO1133 | 0.25 | g/10min | |||
Thermisch | Voorwaarde | Standaard | Waarde | Eenheid | |||
Smeltend | Temperatuur | ISO11357 | 110 | °C | |||
Vicat | Verzachtingstemperatuur 50°C/uur 10N | ISO306 | 96 | °C |
05 | Comparative Analysis with Other General-Purpose LDPE Grades
Performance Metric | LUPOLEN LDPE 2420D | Conventional General-Purpose LDPE | Voordelen |
Melt Strength | Hoog | Medium | Improved film formation stability |
Additive Content | None | Present | Suitable for high-purity or contamination-sensitive applications |
Tensile Strength (MD) | 27 MPa | 20–24 MPa | Greater load-bearing capacity in packaging |
Dart Drop Impact | 250 g | 150–200 g | Enhanced resistance to impact and rupture during transportation |
Melt Index (MI) | 0.25 g/10 min | 0.5–2.0 g/10 min | More suitable for thick film and multi-layer co-extrusion |
06 | Sustainable perspective: energy saving and controllable formula
LUPOLEN LDPE 2420D helps customers ensure physical properties while controlling melt index and modulus parameters:
Realize film weight reduction: increase finished product area per unit weight and reduce material waste;
Customized additive system: blank formula allows users to develop modified grades such as anti-purple and anti-fog on demand;
Reduce processing energy consumption: low MI design reduces shear heat and is suitable for long-cycle, energy-saving production lines;
Compatible with recycling: can be blended and reused with PE recycling system to help build a closed-loop packaging system.
07 | Real scenario cases of downstream customers
Case 1: A large flexible packaging company uses LDPE 2420D to replace a variety of low-performance film materials, reducing film thickness by 12% and improving the unit tensile performance of packaging bags by 18%.
Case 2: Southeast Asian agricultural film manufacturers reported that greenhouse films made of LDPE 2420D plastics still maintain good ductility and stability in high temperature and high humidity climates, and no film breakage was found.
08 | Why choose us: From material selection to long-term supply, we escort you
✔ 100% original factory direct supply, stable quality
All LDPE 2420D particles come from LyondellBasell original factory, ensuring product batch consistency and traceability;
✔ Adequate stock, flexible delivery
Regular packaging specifications are available in stock, supporting small batch sample shipments or long-term contract procurement models;
✔ Professional material selection guidance, fast response
Whether you are making bag film, shrink film, or agricultural film blowing, we provide customized material selection suggestions and processing support services;
✔ Welcome to obtain samples and technical information
If you need TDS, MSDS, quotation, or want to know more application suggestions, please contact us through the contact information on the right side of the page!
